Product Description
BlocknZorbe™ Multi-Purpose Sound Panels
Product Information
- Semi-rigid, porous expanded polypropylene sound panels are the only acoustical panels to both BLOCK and ABSORB noise
- Install directly on walls or ceilings
- Lightweight and easy to clean
- Water resistant, impact resistant, and tack-able
- Use indoors or outdoors (Charcoal)
- Temperature rated up to 230°F
- R-Value of 3.8 per inch
- Class A Fire Rated
- Easy to install and easy to clean
- Proudly made in the USA
Specs
- Size: 24" x 24" (24" x 48" available via phone)
- Weight: 1 lb (1"), 2 lbs (2")
- Thickness: 1" or 2"
- Edge: Square
- Colors: Charcoal, White
| Spec Sheet | BlocknZorbe Product Sheet |
| Architect CSI Specs |
BlocknZorbe Wall Panel CSI Spec |
| Install Guides | BlocknZorbe Install Guide (Adhesive) BlocknZorbe Install Guide (Direct Attach) |
Product Uses
- Homes, diy soundproofing for apartments, pool pump noise reduction, skating rinks, dog kennels, golf simulator wall padding, rooftop and machine enclosures, generator sound box, soundproof shooting box, offices, gymnasiums, auditoriums, schools, classrooms, cafeterias, sound proof a door, manufacturing plants, and warehouses
- One of the only acoustic panels that are actually also soundproofing panels (rated for NRC and STC)
- For apartments, screw into the wall with 100% coverage as a DIY solution for soundproofing existing walls that you can take with you when you move.
- Screw into a wood fence facing a busy street (100% coverage) for road noise reduction fence paneling that is also UV resistant (charcoal)
- Sold as custom cut and dropped in as ceiling tiles with BlocknZorbe EZ Drop
- Also used to create sound baffles in HVAC ductwork
Installation Instructions
- Recommended Installation: The easiest way to install BlocknZorbe sound panels is to screw them into the wall or ceiling.
- All screws should be at least 3/4" from the edge of the panel.
- Our recommended adhesives can be used as an optional installation method
- If field cuts are needed, use a table saw. Set blade to cut half the thickness of the BlocknZorbe acoustic material. (i.e. for a 2" thick panel, cut 1" and then flip the panel over and cut 1" again to complete the cut)
- Download the BlocknZorbe Install Guide (Adhesive) or the BlocknZorbe Install Guide (Direct Attach)
Contact us if you have questions!
| Panel Thickness | Substrate | Rec. Screw Type | Rec. Screw Length |
|---|---|---|---|
| 1" | Hat Channel or Thin Metal |
Self-Tapping |
2" |
| 2" | Hat Channel or Thin Metal |
Self-Tapping |
3" |
| 1" | Drywall or Wood Furring | Drywall Screw | 1-5/8" |
| 2" | Drywall or Wood Furring | Drywall Screw | 3" |
| 1" | Concrete | Tapcon | 2-1/4" |
| 2" | Concrete | Tapcon | 3-1/4" |
Noise Reduction Coefficient
| Frequency (Hz) | 125 | 250 | 500 | 1000 | 2000 | 4000 | NRC |
| 1" BlocknZorbe™ Sound Panel | 0.05 | 0.06 | 0.21 | 0.80 | 0.65 | 0.75 | 0.45 |
| 2" BlocknZorbe™ Sound Panel | 0.07 | 0.21 | 0.81 | 0.85 | 0.93 | 0.88 | 0.70 |
Sound Transmission Loss
| Frequency (Hz) | 125 | 250 | 500 | 1000 | 2000 | 4000 | STC |
| 1" BlocknZorbe™ Sound Panel | 6 | 5 | 7 | 8 | 10 | 15 | 9 |
| 2" BlocknZorbe™ Sound Panel | 9 | 8 | 10 | 10 | 17 | 22 | 13 |
| Tested Properties | Testing Method | Performance |
|---|---|---|
| Fire Rating | ASTM E84 |
Class A |
| Fungal Growth | ASTM C1338 |
Pass |
| R-Value | ASTM C177 | 3.8 per inch |
| VOC | CDPH Standard Method v1.2 | Pass |
